Diameter d | Overall Length L | Slot Length L1 |
5/64 | 38 | 7.5 |
3/32 | 43 | 9.5 |
7/64 | 46 | 9.5 |
1/8 | 49 | 11.2 |
9/64 | 52 | 12.5 |
5/32 | 55 | 14 |
11/64 | 58 | 15.5 |
3/16 | 63 | 17 |
13/64 | 63 | 17 |
7/32 | 66 | 19 |
15/64 | 66 | 19 |
1/4 | 70 | 21.2 |
2.0 | 38 | 7.5 |
2.5 | 43 | 9.5 |
3.0 | 46 | 10.6 |
3.2 | 49 | 11.2 |
3.5 | 52 | 12.5 |
4.0 | 55 | 14 |
4.2 | 55 | 14 |
4.5 | 58 | 15.5 |
4.8 | 62 | 17 |
5.0 | 62 | 17 |
5.2 | 62 | 17 |
5.5 | 66 | 19 |
5.8 | 66 | 19 |
6.0 | 66 | 19 |
6.2 | 70 | 21.2 |
6.5 | 70 | 21.2 |
